turbo difference?


  • Please log in to reply
13 replies to this topic

#1 daipug29

daipug29

    Getting to know you

  • Validating
  • PipPip
  • 137 posts
  • Gender:Male
  • Location:Swansea
  • Car:306 td

Posted 08 November 2008 - 12:49 PM

i was just wondering if anyone can tell me if there is a major difference, between the t2 off a gt turbo and the 306?? would these be compatible or would the turbine and compressor have to be changed?
also, can anyone tell me if there is any difference in design i.e head and exhaust manifold fitting between ph1 and 2's 306's aswell as, are the a/r ratio's the same on the two?

#2 Rob_Furious

Rob_Furious

    mad scientist

  • Club-306 VIP
  • 3,809 posts
  • Gender:Male
  • Location:crewe and nantwich
  • Car:97 ph1 GTi-6

Posted 08 November 2008 - 01:11 PM

T2 on pretty much all cars is the same as any other T2. aslong as its called just T2 its the same.

on a 306 there is 4 turbo's to have. the KKK, garret T2, garrett GT15, K03

KKK is the same as a T2 but they have a built in actuator.
T2 is a good turbo can run good boost but doesnt spool that fast, has a removable actuator.
GT15 is a fast spooling turbo but i think they cant run high boost. they are on a slightly diffrent manifold as they are off the HDi's
K03 is the newest of the turbos i dont know what there off but JAC (joe) will know, i think they are HDI and are afast spool aswell.
Posted Image
Team bianca!
Team Sigma!
Team Phase 1 FTMFW!
Team 6 :ph34r:

#3 Jorge

Jorge

    Forum Veteran

  • Validating
  • PipPipPip
  • 864 posts
  • Gender:Male
  • Location:Derby
  • Car:Saxo VTS

Posted 08 November 2008 - 01:56 PM

When you say KKK you mean KKK K14, the worst of the lot.

Largest (worst) to Smallest (best for a diesel)

KKK K14 (fitted to most phase 2s and late phase 1s)
Garret GT2 (fitted to phase 1s mainly) good turbo
GT15 (fitted to the HDI, and late phase 2s, 99> cant fit the HDI one though)
KKK K03 (same as above really, some of these and the gt15s were fitted to DTS too)

#4 Rob_Furious

Rob_Furious

    mad scientist

  • Club-306 VIP
  • 3,809 posts
  • Gender:Male
  • Location:crewe and nantwich
  • Car:97 ph1 GTi-6

Posted 08 November 2008 - 05:04 PM

ok jorge what make the KKK a bad turbo? it spools at the same rate as a T2 it can boost just as much and does everything a T2 does.
Posted Image
Team bianca!
Team Sigma!
Team Phase 1 FTMFW!
Team 6 :ph34r:

#5 Martin

Martin

    Resident Perv

  • AdminRoot Admin
  • 27,214 posts
  • Twitter:@Steelo26581
  • Gender:Male
  • Location:Cumbria!
  • Car:Clio 182

Posted 08 November 2008 - 05:07 PM

Garrett snobs Rob wink.gif

I never had any trouble with either of my KKK's, the K14 or the K03, and often out ran bosch and garrett combos....

#6 daipug29

daipug29

    Getting to know you

  • Validating
  • PipPip
  • 137 posts
  • Gender:Male
  • Location:Swansea
  • Car:306 td

Posted 08 November 2008 - 05:11 PM

QUOTE (Jorge @ Nov 8 2008, 02:56 PM) <{POST_SNAPBACK}>
When you say KKK you mean KKK K14, the worst of the lot.

Largest (worst) to Smallest (best for a diesel)

KKK K14 (fitted to most phase 2s and late phase 1s)
Garret GT2 (fitted to phase 1s mainly) good turbo
GT15 (fitted to the HDI, and late phase 2s, 99> cant fit the HDI one though)
KKK K03 (same as above really, some of these and the gt15s were fitted to DTS too)


i have a ph2 and its a 99 t reg,im sure its a t2, defo a garrett.
Basically i have got q leaking compressor seal and would like to renew, so have aquired a second-hand turbo,am just making sure the turbo i have will fit the car!!!

#7 Rob_Furious

Rob_Furious

    mad scientist

  • Club-306 VIP
  • 3,809 posts
  • Gender:Male
  • Location:crewe and nantwich
  • Car:97 ph1 GTi-6

Posted 08 November 2008 - 05:46 PM

aslong as its any of them turbos its will pretty much bolt straight on.

Posted Image
Team bianca!
Team Sigma!
Team Phase 1 FTMFW!
Team 6 :ph34r:

#8 DevDturbo

DevDturbo

    Underwater ceramic analysist

  • Club-306 VIP
  • 997 posts
  • Gender:Male
  • Location:oxford brookes uni
  • Car:'95 D-turbo

Posted 08 November 2008 - 06:59 PM

What will the turbo on mine be? (1995 Phase 1 Dturbo).
Thats not gone well!!

#9 ash1293

ash1293

    More posts than sense

  • Club-306 VIP
  • 2,292 posts
  • Gender:Male
  • Location:York

Posted 08 November 2008 - 07:08 PM

QUOTE (daipug29 @ Nov 8 2008, 05:11 PM) <{POST_SNAPBACK}>
i have a ph2 and its a 99 t reg,im sure its a t2, defo a garrett.



Yours is prob a gt15, my 99 dt is. Don't think the t2 made its way into the 306 this late on in production. Last of the 1.9dt's rolled off in 1999 irc.

QUOTE (DevDturbo @ Nov 8 2008, 06:59 PM) <{POST_SNAPBACK}>
What will the turbo on mine be? (1995 Phase 1 Dturbo).



More than likley a GT2 or poss a kkk.
Posted Image

#10 CdoPete

CdoPete

    Newbie

  • Validating
  • Pip
  • 27 posts
  • Gender:Male
  • Location:Alnwick, Northumberland
  • Car:306 hdi

Posted 13 December 2008 - 10:10 PM

what about a 2000 w plate hdi turbo? any ideas on which would be best also can you get up rated acuator? mine is going to be running around 130bhp after re-map
I Need Help To Sort Out My Hdi Power Problem

#11 Apple

Apple

    Do NOT feed me skittles

  • Club-306 VIP
  • 7,330 posts
  • Gender:Male
  • Location:Derbyshire
  • Car:205, Focus, 306

Posted 13 December 2008 - 10:16 PM

it will be a GT15 and will happily run 130hp
https://www.facebook.com/GuidedByFire <<<<<<< Click me and check out my band!

#12 CdoPete

CdoPete

    Newbie

  • Validating
  • Pip
  • 27 posts
  • Gender:Male
  • Location:Alnwick, Northumberland
  • Car:306 hdi

Posted 13 December 2008 - 10:36 PM

are these better than the garret t2.........also any differences so i know what im looking for on tues so i can tell the difference
I Need Help To Sort Out My Hdi Power Problem

#13 Apple

Apple

    Do NOT feed me skittles

  • Club-306 VIP
  • 7,330 posts
  • Gender:Male
  • Location:Derbyshire
  • Car:205, Focus, 306

Posted 13 December 2008 - 10:38 PM

yeah, they seem to be better, faster smoother spooling with higher boost levels

as for differences, the T2 and GT15 are nigh on identical bar the identification plate
https://www.facebook.com/GuidedByFire <<<<<<< Click me and check out my band!

#14 Tobster

Tobster

    Forum Veteran

  • Club-306 VIP
  • 472 posts
  • Gender:Male
  • Location:North York Moors
  • Car:306 2.1TD

Posted 15 December 2008 - 03:38 PM

QUOTE (Rob_Furious @ Nov 8 2008, 06:04 PM) <{POST_SNAPBACK}>
ok jorge what make the KKK a bad turbo?


Mine is dying epically.

With wastegate fully closed it manages 15psi for a brief moment then stops at 3000rpm and the car smokes like a bastard.
When the car's cruising it's giving -1psi (going backwards!).

No leaks anywhere.
